The Wolverine X2 XT-R features a range of refinements that further boost capability, confidence and comfort in rough terrain. The robust new chassis is kitted out in top-shelf XT-R trim including durable 27-inch radial tyres, a WARN® VRX 4500 winch, and high-quality painted body and graphics package with colour-matched aluminium wheels.

Power is provided by the smooth 847cc twin cylinder engine and comfort provided by high back seating with plenty of legroom.

Wolverine X2 XT-R - when the going gets XT-Reme.

> Smooth and powerful 847cc twin
cylinder powerplant
> KYB piggyback gas shocks
> Dual-range Ultramatic transmission
> 2WD, 4WD & 4WD with diff-lock
On-Command drive system
> Speed management system
> 272kg capacity hydraulic assisted
rear cargo bed
> XT-R package includes WARN VRX
winch, tough 27in Dirt Commander
tyres & colour matched aluminium
wheels

  • Engine TypeLiquid-cooled, 4-stroke, DOHC, parallel twin
  • Displacement (cc)847.0
  • Bore x Stroke (mm)82.0 x 80.2
  • Compression Ratio10.5 : 1
  • Lubrication System Dry sump
  • Fuel Management Fuel Injection
  • Ignition TCI
  • Starter System Electric
  • Fuel Tank Capacity (L)35.0
  • Final Transmission Shaft
  • Transmission Ultramatic® V-belt, On-Command® 2WD, 4WD, 4WD with Diff-lock
  • Frame Type Steel tube
  • Suspension Front Independent double wishbone, 221mm wheel travel
  • Suspension Rear Independent double wishbone, 236mm wheel travel
  • Brakes Front Hydraulic dual discs
  • Brakes Rea rHydraulic dual discs
  • Tyres Fron t27 x 9-12
  • Tyres Rear 27 x 11-12
  • Length (mm)2920
  • Width (mm)1580
  • Height (mm)1913
  • Seat Height (mm)
  • Wheelbase (mm)2100
  • Ground Clearance (mm)293
  • Wet Weight (kg)773
