Equipped with Yamaha's Ultramatic® transmission, the Wolverine® RMAX™2 1000 Sport offers unmatched off-road capability. The CVT system includes a centrifugal clutch and a constant-tension belt system, making gear switching less frequent and off road adventures more fun. Enjoy seamless handling of obstacles at high revs and choose a low gear for increased torque in challenging conditions.

Super striking in Team Yamaha Blue with ultra stylish wheel accents, the Wolverine® RMAX™2 1000 Sport also offers a premium sport interior for comfort and style. With ultra-plush cut-and-sew seats in Yamaha Blue, both driver and passengers can tackle rugged backcountry adventures in ultimate comfort and style. Pair that with 3 drive modes and adjustable EPS and you're set for anything the terrain can throw at you.

> Powerful and smooth 999cc parallel
twin engine
> Unique three-position D-Mode
switch
> Fox® 2.0 suspension package
> On-Command 4WD drive system with
turf mode
> Selectable electric power steering
> 2000kg WARN VRX winch
> 272kg capacity hydraulic assisted
rear cargo bed

  • Engine Type Liquid-cooled, 4-stroke, DOHC, parallel twin
  • Displacement (cc)999.0
  • Bore x Stroke (mm)93.0 x 73.5
  • Compression Ratio 11.2 : 1
  • Lubrication System Dry sump
  • Fuel Management Fuel Injection
  • Ignition TCI
  • Starter System Electric
  • Fuel Tank Capacity (L)34.8
  • Final Transmission On-Command 4-way locking differential; Turf Mode, 2WD, 4WD, full diff-lock 4WD
  • Transmission Ultramatic® V-belt, On-Command® 2WD, 4WD, 4WD with Diff-lock
  • Frame Type Steel tube
  • Suspension Front Independent double wishbone w/anti-sway bar, FOX 2.0 piggyback shocks; 360mm travel
  • Suspension Rear Independent double wishbone w/anti-sway bar, FOX 2.0 piggyback shocks; 430mm travel
  • Brakes Front Hydraulic dual discs
  • Brakes Rear Hydraulic dual discs
  • Tyres Front 30 x 10.00R-14 GBC Terra Master
  • Tyres Rear 30 x 10.00R-14 GBC Terra Master
  • Length (mm)3030
  • Width (mm)1680
  • Height (mm)1976
  • Seat Height (mm)
  • Wheelbase (mm)2202
  • Ground Clearance (mm)351
  • Wet Weight (kg)
