The Grizzly 110 is built to bring maximum fun for young ATV riders ages 10 and up. Featuring a new, larger displacement 112cc engine with advanced fuel injection tuned to deliver excellent low- to mid-range performance, the new Grizzly 110 is the perfect platform for allowing young riders to build skill and confidence.

Scaled down not scaled back Compact A-arm front suspension is tuned for light, sporty steering and comfortable ride quality. The preload-adjustable front shocks offer 127mm of wheel travel and add to the 110’s full-size ATV look. The rear swingarm also features a 5-way preload adjustable shock, offering 145mm of wheel travel.

Fully automatic, continuously variable transmission (CVT) means no shifting. Handy for all riders aged 10-years old and up, it’s a feature that beginner riders particularly appreciate. Standard reverse gear adds convenience.

Robust steal cargo racks front and rear give younger riders the ability to pack their own gear as they join the family on their next adventure.

ENGINE

  • Engine TypeAir-cooled, 4-stroke, SOHC, 2-valve, single cylinder
  • Displacement (cc)112
  • Bore x Stroke (mm)52.4 x 51.8
  • Compression Ratio9.2 : 1
  • Lubrication SystemWet sump
  • Fuel ManagementFuel Injection
  • IgnitionTCI
  • Starter SystemElectric
  • Fuel Tank Capacity (L)6.8
  • Final TransmissionChain
  • TransmissionV-belt automatic, F, N, R

CHASSIS

  • Frame TypeSteel tube
  • Suspension FrontSingle A-arm, 127mm travel
  • Suspension RearSwingarm, 145mm travel
  • Brakes FrontDual drums
  • Brakes RearDrum
  • Tyres FrontAT19 x 7-8
  • Tyres RearAT18 x 9-8

DIMENSIONS

  • Length (mm)1562
  • Width (mm)1030
  • Height (mm)1005
  • Seat Height (mm)730
  • Wheelbase (mm)1030
  • Ground Clearance (mm)105
  • Wet Weight (kg)143
