The 2024 KTM 250 EXC presents enduro riders with the ultimate combination of power and rideability, setting the benchmark in the highly contested E1 class. Thanks to its groundbreaking new frame, suspension, and TBI technology, this extreme machine continues to reach new heights. How far you push, thought, it is up to you.

  • New Ultra Light Subframe
  • WP XACT Closed-Cartidge Fork
  • Selectable Engine Maps (optional extra)
  • Throttle Body Injection - TBI

ENGINE

  • TRANSMISSION 6-speed
  • STARTER Electric starter
  • STROKE 72 mm
  • BORE 66.4 mm
  • CLUTCH Wet, DDS multi-disc clutch, Brembo hydraulics
  • DISPLACEMENT 249 cm³
  • EMS Vitesco Technologies EMS
  • DESIGN 1-cylinder, 2-stroke engine

CHASSIS

  • WEIGHT (WITHOUT FUEL) 104.9 kg
  • TANK CAPACITY (APPROX.) 9 l
  • FRONT BRAKE DISC DIAMETER 260 mm
  • REAR BRAKE DISC DIAMETER 220 mm
  • FRONT BRAKE Disc brake
  • REAR BRAKE Disc brake
  • CHAIN 520 X-Ring
  • FRAME DESIGN Central double-cradle-type 25CrMo4 steel
  • FRONT SUSPENSION WP XACT-USD, Ø 48 mm
  • GROUND CLEARANCE 347 mm
  • REAR SUSPENSION WP Xplor PDS shock absorber
  • SEAT HEIGHT 963 mm
  • STEERING HEAD ANGLE 63.9 °
  • SUSPENSION TRAVEL (FRONT) 300 mm
  • SUSPENSION TRAVEL (REAR) 310 mm
