The 2024 TC 250 features the very latest in technical innovations to retain its position on the top step of the competitive 250 cc 2-stroke motocross class. With E-Start and electronic fuel injection, starting is simplified while performance on track remains unrivalled thanks to the highly sophisticated EFI system that delivers the perfect air/fuel ratio for instant, controllable power at all times. Expertly assembled with premium components throughout, the TC 250 also benefits from exceptional build quality, which guarantees both performance and reliability. Finished with new graphics inspired by the brand's Swedish heritage, the decals are applied to the ergonomic bodywork using in-mold technology for a striking look and a long-lasting finish.

ENGINE
Transmission
5-speed
Battery Capacity
2 Ah
Cooling
Liquid cooled
Starter
Electric Starter
Stroke
72 mm
Bore
66.4 mm
Clutch
Wet, DDS multi-disc, Brembo hydraulics
Displacement
249 cm³
EMS
Vitesco Technologies EMS
Design
1-Cylinder, 2-Stroke Engine
CHASSIS
Weight (without fuel)
99.6 kg
Tank Capacity (APPROX.)
7.2 L
Front brake disc diameter
260 mm
Rear brake disc diameter
220 mm
Front brake
Disc brake
Rear brake
Disc brake
Chain
520, Non-sealed
Frame design
Central double-cradle-type 25CrMo4 steel
Front suspension
WP XACT-USD, Ø 48 mm
Ground clearance
346 mm
Rear suspension
WP XACT Monoshock with linkage
Seat height
939 mm
Steering head angle
63.9 °
Suspension travel (Front)
305 mm
Suspension travel (Rear)
293 mm
