Husqvarna FE 501 2024

Enhanced with the latest technical innovations and producing more power than the previous generation, the FE 501 continues to be the most powerful machine in the Husqvarna Motorcycles enduro line-up. A new engine for 2024 produces a broader spread of controllable power and by positioning the engine shaft arrangements at the ideal centre of gravity, this vastly benefits manoeuvrability. Aiding this agile feel is the new chassis, which has been developed and manufactured using advanced engineering techniques, which together with new WP Suspension ensures enhanced comfort across rough terrain. Expertly assembled with high-quality components throughout, the FE 501 is finished with new functional bodywork adorned with white, yellow, and blue graphics inspired by the Swedish heritage of the brand.

  • New Chromium molybdenum steel frame optimised for improved anti-squat behaviour and enhanced flex characteristics
  • New WP XACT rear shock is lighter and developed specifically for enduro riding
  • New BRAKTEC brake system and high-performance GSK discs provide superior stopping power
  • New multifunctional Map Select Switch design controls the Quickshifter and Traction Control

ENGINE

  • TRANSMISSION 6-speed
  • STARTER Electric starter
  • STROKE 72 mm
  • BORE 95 mm
  • CLUTCH DDS wet multi-disc clutch, Braktec hydraulics
  • DISPLACEMENT 510.9 cm³
  • EMS Keihin EMS
  • DESIGN 1-cylinder, 4-stroke engine

CHASSIS

  • WEIGHT (WITHOUT FUEL) 110.8 kg
  • TANK CAPACITY (APPROX.) 8 l
  • FRONT BRAKE DISC DIAMETER 260 mm
  • REAR BRAKE DISC DIAMETER 220 mm
  • FRONT BRAKE Disc brake
  • REAR BRAKE Disc brake
  • CHAIN 520 X-Ring
  • FRAME DESIGN Central double-cradle-type 25CrMo4 steel
  • FRONT SUSPENSION WP XACT-USD, Ø 48 mm
  • GROUND CLEARANCE 343 mm
  • REAR SUSPENSION WP Xplor PDS shock absorber
  • STEERING HEAD ANGLE 63.9 °
  • SUSPENSION TRAVEL (FRONT) 300 mm
  • SUSPENSION TRAVEL (REAR) 300 mm
